Description

Product Features

  • Pure sine wave
  • Power factor 1.0
  • PV input 500Vdc Max
  • Built-in MPPT 100A
  • Capable to work without battery
  • Detachable dust cover for harsh environment
  • WiFi remote monitoring optional
  • Compatible work with lifepo4 battery
  • Support multiple output priority: UTL, SOL, SBU, SUB
  • Parallel operation of up to 12 units in 1phase or 3phase
  • EQ function to optimize battery performance and extend the lifecycle

Technical Data

MODEL

T5500-48 Plus

Capacity

5.5KVA/5.5KW

Parallel Capability

YES,12 Units

INPUT

Nominal Voltage

230VAC

Acceptable Voltage Range

170-280VAC(For personal Computer);90-280vac(For Home Appliances)

Frequency

50/60 Hz(Auto sensing)

OUTPUT

Nominal Voltage

220/230VAC±5%

Surge Power

11000VA

Frequency

50/60Hz

Waveform

Pure Sine wave

Transfer Time

10ms(For personal Computer);20ms(For Home Appliances)

Peak Efficiency(PV to INV)

96%

Peak Efficiency(Battery to INV)

93%

Overload Protection

5s@>=150% load; 10s@110%~150% load

Crest Factor

3:1

Admissible Power Factor

0.6~1(inductive or capacitive)

BATTERY

Battery Voltage

48VDC

Floating Charge Voltage

54VDC

OverCharge Protection

63VDC

Charging Method

CC / CV

Solar Charger & AC Charger

Solar Charger Type

MPPT

Max.PV Array Power

5500W

Max.PV Array Open Circuit Voltage

500VDC

PV Array MPPT Voltage Range

120VDC~450VDC

Max.Solar Input Current

18A

Max.Solar Charge Current

100A

Max.AC Charge Current

60A

Max.Charge Current

100A

PHYSICAL

Dimensions,D x W x H(mm)

448x295x122

Package Dimensions,D x W x H(mm)

540x390x210

Net Weight(Kg)

10

Communication Interface

RS485/ RS232 / Dry-contact

ENVIRONMENT

Operating Temperature Range

(-10°C to 50°C)

Storage Temperature

(-15°C ~ 50°C)

Humidity

5% to 95% Relative Humidity ( Non-condensing )



T5500-48-Plus-Hybrid-Solar-Inverter-5.5kw-data-sheet.pdf
